Modeling Conventions

The synchronization between UML models and programming code is achieved using a set of modeling conventions (mappings) between UML constructs and programming code syntax. The Software Engineer is advised to become familiar with these conventions in order to work with the code generation process for the programming languages they intend to target. There are a range of constructs used, including elements, features, connectors, connector ends, stereotypes and Tagged Values. The newcomer will require a little time to become familiar with these conventions but after a short time they will be translating between programming code and UML constructs without effort.

Supported Languages

Language

See also

Action Script

ActionScript

Ada 2012 (Systems Engineering and Ultimate editions)

Ada 2005

C

C

C#

C#

C++

C++

Delphi

Delphi

Java

Java

PHP

PHP

Python

Python

SystemC (Systems Engineering and Ultimate editions)

SystemC

Verilog (Systems Engineering and Ultimate editions)

Verilog

VHDL (Systems Engineering and Ultimate editions)

VHDL

Visual Basic

Visual Basic

Visual Basic .NET

Visual Basic .NET

Notes

Enterprise Architect incorporates a number of visibility indicators or scope values for its supported languages; these include, for:

  • All languages - Public (+), Protected (#) and Private (-)
  • Java - Package (~)
  • Delphi - Published (^)
  • C# - Internal (~), Protected Internal (^)
  • ActionScript - Internal (~)
  • VB.NET - Friend (~), Protected Friend (^)
  • PHP - Package (~)
  • Python - Package (~)
  • C - Package (~)
  • C++ - Package (~)
