Enterprise Architect is a collaborative modeling, design and management platform based on UML and related standards. Agile, intuitive and extensible with fully integrated, powerful domain specific high-end features at a fraction of the cost of many competitors. An enterprise wide solution for visualizing, analyzing, modeling, testing and maintaining a wide range of systems, software, processes and architectures. Team based, with a proven track record and over 300,000 users worldwide; Enterprise Architect is the scalable, standards compliant toolset that is perfect for your next project.

Enterprise Architect

Enterprise Architect Free Downloads

The latest version of Enterprise Architect is: Version Build , released .

Note: If you are a registered user and would like to update to the latest version of Enterprise Architect, please visit the Registered Download Page. You will require your username and password for access.


Enterprise Architect FREE Trial Edition

Our Trial edition of the Enterprise Architect UML modeling tool provides a time-limited, fully functional installation, giving you the opportunity to assess all features in detail. The trial period lasts 30 days. Visit the Trial Download page for a FREE evaluation of Enterprise Architect.

If you are installing the Trial edition on Linux or Intel Mac please refer to the Enterprise Architect on Linux page.

If you have trouble downloading large files, you can purchase the Enterprise Architect 30 day Trial on CD at a cost of US$15 plus US$3 delivery (total US$18). Delivery takes approximately 1-2 weeks.

Additional Resources

Shared (DBMS) Model Repositories
If you wish to trial Enterprise Architect using a shared DBMS model repository, you will need to download and run the appropriate database SQL script, from the Enterprise Architect Trial Edition Corporate Resources.


User (Role-Based) Security in the Trial Edition
User Security is a feature of the Corporate Edition of Enterprise Architect. To enable and evaluate the role-based security functionality of your trial edition, you will require the following key:
    {C27378C8-6CD8-4efa-92F8-4E0E4F1A8B65}


Enterprise Architect Help Files

To learn more about Enterprise Architect without downloading the full package, you may download the help files separately or view the User Guide online.

 EAUserGuide.pdf
  Total size: Updated:
 EA.chm
  Total size: Updated:

Note: If you experience problems loading the .CHM help file, you may need the HTML Help install files. Internet Explorer 7 also may not open .CHM files over a network. As a work around, copy the CHM help file to your local drive, open the file’s properties and select the Unblock button (if displayed).


Enterprise Architect Viewer
Enterprise Architect Lite provides a free viewer for Enterprise Architect models. This read-only edition is intended for distribution with UML models, to staff or to customers. It supports all viewing functions, however document generation and model editing abilities have been disabled.

 EALite.exe
  Total size: Build: Updated:


Documentation
Download DocExample.zip, if you are interested in the quality and type of documentation that Enterprise Architect can output, this example shows some of the capabilities of the package. Enterprise Architect generates output Rich Text Format files for various parts of the model, which have then been combined into one document using a Microsoft Word master document.


Enterprise Architect Template Projects
If required, you can download the latest EABase.eap file, which is an empty starter project. Note that the latest EABase.eap is also distributed with both the trial and registered installations.
